【Domestic Papers】Researchers from Xi’an Institute of Optics and Precision Mechanics investigated highly sensitive Ga₂O₃ MSM solar-blind UV photodetector with impact ionization gain

      Researchers from the Xi’an Institute of Optics and Precision Mechanics (XIOPM) have published a dissertation titled "Highly sensitive Ga₂O₃ MSM solar-blind UV photodetector with impact ionization gain" in Optics Express.

Abstract

      In this study, a (400) crystal-oriented β-Ga₂O₃ thin film with a thickness of approximately 400 nm was grown on a c-plane sapphire substrate using atomic layer deposition. Schottky contact-type metal-semiconductor-metal solar-blind ultraviolet detectors with an Au/Ni/Ga₂O₃/Ni/Au structure were fabricated on the epitaxial thin films. The Schottky barrier height is about 1.1 eV. The device exhibited a high responsivity of up to 800 A/W, and a detectivity of 6 × 10¹⁴ Jones while maintaining a relatively fast response speed with a rise time of 4 ms and a fall time of 12 ms. The photo-to-dark current ratio was greater than 10³, and the external quantum efficiency exceeded 10³, indicating a significant gain in the device. Through the analysis of TCAD simulation and experimental results, it is determined that the impact ionization at the edge of the MSM electrode and channel contact is the main source of gain. Barrier tunneling effects and the photoconductive effect due to different carrier mobilities were not the primary reasons for the gain.

Fig. 1.Schematic diagram of MSM device structure.

Fig. 2. (a) The I-V and (b) I-t test circuit schematic graphs.

DOI：

https://doi.org/10.1364/OE.531784
